Table 6: Fan Status LEDs
(Connued)
Label Color State Descripon
On steadily Soware inializaon is
complete, and the fan is
funconing normally.
Yellow On steadily Equipment is faulty and
malfunconing.
Dark O Fan tray input power
failure
Airow
The router has a front-to-back (AIR OUT) cooling system (see Figure 9 on page 20). Air is pulled
through the front of the chassis toward the fan trays, which exhaust the air out of the router.
