Figure 7: Fan Status LEDs on the Front of the Router
Figure 8: Fan Status LEDs on the Rear of the Router
1—
Fan tray
3—
Two-hole protecve grounding terminal
2—
Fan tray LEDs
Table 6 on page 18 describes the behavior of the fan LED.
Table 6: Fan Status LEDs
Label Color State Descripon
STATUS (Fan status) Green Blinking Fan hardware inializaon
is complete. Soware
inializaon is pending.
18
