Table 4: Timing Ports LEDs on the ACX7348 Chassis

(Connued)

LED Color State Descripon

BITS Green On steadily Clock is acve.

Yellow On steadily Loss of clock.

ACX7348 Physical Specicaons

Table 5: ACX7348 Router Chassis and Component Physical Specicaons

Descripon Weight Height Width Depth

ACX7338 Chassis Chassis without any

FRUs- 25.53 lb

(11.58 kg)

5.21 in. (13.23 cm) 16.92 in. (42.97 cm) 11.41 in. (28.98 cm)

Roung Engine 2.14 lb (0.97 kg) 0.88 in. (2.23 cm) 6.75 in. (17.14 cm) 8.33 in. (21.15 cm)

ACX7300-

FPC-2CD4C

2.13 lb (0.96 kg) 1.65 in. (4.19 cm) 5.40 in. (13.71 cm) 5.40 in. (13.71 cm)

AC power supply

module

2.43 lb (1.10 kg) 1.53 in. (3.88 cm) 2.89 in. (7.34 cm) 7.28 in. (18.49 cm)

DC power supply

module

2.24 lb (1.01 kg) 1.53 in. (3.88 cm) 2.89 in. (7.34 cm) 7.28 in. (18.49 cm)

Fan tray 1.38 lb (0.62 kg) 5.07 in. (12.87 cm) 2.81 in. (7.13 cm) 3.04 in. (7.72 cm)

Roung Engine

Blank

0.21 lb (0.09 kg) 0.90 in. (2.28 cm) 6.75 in. (17.14 cm) 1.00 in. (2.54 cm)
