ACX7348 Management and Console Port
Specicaons and Pinouts
SUMMARY
IN THIS SECTION
Management Cable Specicaons for
ACX7348 Routers | 66
Management Port Connector Pinout
Informaon for ACX7348 Routers | 67
Console Port Connector Pinout on ACX7348
Routers | 67
Management Cable Specicaons for ACX7348 Routers
Table 29 on page 66 lists the specicaons for the cables that connect the console and management
ports to management devices.
Table 29:
Specicaons of Cables to Connect to Management Devices
Ports Cable Specicaons Receptacle Addional Informaon
Console (CON) port RS-232 (EIA-232) serial
cable
RJ-45 "Connect an ACX7348
Router to a Management
Console" on page 87
Management (MGMT)
port
Ethernet cable with an
RJ-45 connector
RJ-45 "Connect an ACX7348
Router to a Network for
Out-of-Band
Management" on page
88
