Table 24: Cable Signals for 12-Fiber Ribbon Patch Cables
Fiber Signal
1 Tx0 (Transmit)
2 Tx1 (Transmit)
3 Tx2 (Transmit)
4 Tx3 (Transmit)
5 Unused
6 Unused
7 Unused
8 Unused
9 Rx3 (Receive)
10 Rx2 (Receive)
11 Rx1 (Receive)
12 Rx0 (Receive)
Table 25: Cable Pinouts for 12-Fiber Ribbon Patch Cables
MPO Pin MPO Pin
1 12
