Juniper AP32 User Manual

Figure 28: Mount the AP on a 1/2-in. Threaded Rod
Mount an AP32, AP33, AP41, or AP43 Access Point on a 5/8-Inch
Threaded Rod
To mount an AP32, AP33, AP41, or AP43 on a 5/8-in. threaded rod, you'll need to use the APBR-T58
mounng bracket that you'll need to order separately.
1. Aach the APBR-T58 bracket to the threaded rod by using the lock washer and nut provided.
Figure 29: Aach the APBR-T58 Bracket to a 5/8-in. Threaded Rod
2. Aach four shoulder screws to the AP if the AP did not ship with the shoulder screws aached.
34

Juniper AP32 Specifications

General

Brand	Juniper
Model	AP32
Category	Wireless Access Point
Language	English
