Juniper AP32 User Manual

Video:
Video:
Mount an Access Point on a Double-Gang Juncon Box
You can mount an access point (AP) on a double-gang juncon box by using the universal mounng
bracket (APBR-U) that we ship along with the AP. To mount an AP on a double-gang juncon box:
1. Aach the mounng bracket to the double-gang juncon box by using four screws. Ensure that you
insert the screws in the holes marked 2 as shown in Figure 6 on page 21.
Figure 6: Aach the APBR-U Mounng Bracket to the Double-Gang Juncon Box
2. Extend the Ethernet cable through the bracket.
3. Posion the AP such that the shoulder screws on the AP engage with the keyholes of the mounng
bracket. Slide and lock the AP in place.
21
