NOTE: The circuit breaker may bounce back to the off (O) position if you
move the breaker too quickly.
NOTE: If more than one power supply is being installed, turn on all power
supplies at the same time.
Figure 54: Installing a DC Power Supply
g005005
Figure 55: Connecting the DC Power Cables
g005006
Replacing an MX5, MX10, MX40, and MX80 DC Power Supply Cable
•
Disconnecting an MX5, MX10, MX40, and MX80 DC Power Supply Cable on page 123
•
Connecting an MX5, MX10, MX40, and MX80 DC Power Supply Cable on page 124
Copyright © 2019, Juniper Networks, Inc.122
MX5, MX10, MX40, and MX80 Universal Routing Platforms Hardware Guide
