Juniper MX80 Hardware Guide

Initially Configuring MX5, MX10, MX40, and MX80 Routers
The MX5, MX10, MX40, and MX80 routers are shipped with the Junos operating system
(OS) preinstalled and ready to be configured when the router is powered on. Two 4-GB
internal NAND flash devices (da0 and da1) are located on the baseboard. The USB storage
device (da2) can be inserted into the slot in the front panel faceplate. The two NAND
flash devices act as the primary boot device (da0) and hard drive (da1).
When the router boots, it first attempts to start the image on the USB flash drive. If a
USB flash drive is not inserted into the router or the attempt otherwise fails, the router
next tries the primary boot device, and then tries the secondary boot device.
You configure the router by issuing Junos OS command-line interface (CLI) commands,
either on a console device attached to the Routing Engine CONSOLE port on the front
panel, or over a telnet connection to a network connected to the Routing Engine
ETHERNET port on the front panel.
Gather the following information before configuring the router:
•
Name the router will use on the network
•
Domain name the router will use
•
IP address and prefix length information for the Ethernet interface
•
IP address of a default router
•
IP address of a DNS server
•
Password for the root user
This procedure connects the router to the network but does not enable it to forward
traffic. For complete information about enabling the router to forward traffic, including
examples, see the Junos OS configuration guides.
To configure the software:
1. Verify that the router is powered on.
2. Log in as the “root” user. There is no password.
3. Start the CLI.
root# cli
root@>
4. Enter configuration mode.
cli> configure
[edit]
root@#
93Copyright © 2019, Juniper Networks, Inc.
Chapter 3: Initial Installation and Configuration

Juniper MX80 Specifications

General

Model	MX80
Category	Network Router
Throughput	80 Gbps
Power Supply	AC or DC
Operating System	Junos OS
Memory	4 GB
Height	1U
