Juniper MX80 Hardware Guide

Table 12: Power Supply LED
DescriptionStateColor
Power supply is functioning normally.On steadilyBlue
Power supply has failed.BlinkingRed
PEM is in offline mode.OfflineRed
MX5, MX10, MX40, and MX80 Routers AC Power Specifications
Table 13 on page 35 lists the AC power system electrical specifications.
Table 13: AC Power System Electrical Specifications
SpecificationItem
Operating range: 90 to 264 VACAC input voltage
50 to 60 Hz (nominal)AC input line frequency
6 A @ 110 VAC (7 A maximum per inlet at 90 VAC) or 3 A @ 220 VACAC system current rating
610 WAC system input power
Table 14 on page 35 lists the AC power supply electrical specifications.
Table 14: AC Power Supply Electrical Specifications
SpecificationItem
500 WMaximum output power
Operating range: 90 to 264 VAC (nominal)AC input voltage
50 to 60 Hz (nominal)AC input line frequency
6 A @ 110 VAC or 3 A @ 220 VAC maximumAC input current rating
See Also AC Power Electrical Safety Guidelines and Warnings for MX5, MX10, MX40, and MX80
Routers on page 167
•
Power Consumption for an AC-Powered MX5, MX10, MX40, and MX80 Router
To allow for future growth so that you can operate the router in any hardware configuration
without upgrading the power infrastructure, we recommend that you provision
6 A @ 110 VAC (660 W) or 3 A @ 220 VAC (660 W) for each input.
35Copyright © 2019, Juniper Networks, Inc.
Chapter 1: Overview

Juniper MX80 Specifications

General

Model	MX80
Category	Network Router
Throughput	80 Gbps
Power Supply	AC or DC
Operating System	Junos OS
Memory	4 GB
Height	1U
