MX5, MX10, MX40, and MX80 Routers Physical Specifications
Table 33 on page 61 summarizes the physical specifications for the router.
Table 33: MX5, MX10, MX40, and MX80 Physical Specifications
HeightDepthWidthWeightDescription
3.5 in. (8.9 cm)23.46 in. (59.6 cm)
(including cable
management bracket
and MIC release lever)
17.5 in. (44.5 cm)Chassis with fan tray
and power supplies:
28 lb (12.7 kg)
Fixed chassis
3.5 in. (8.9 cm)23.46 in. (59.6 cm)
(including cable
management bracket
and MIC release lever)
17.5 in. (44.5 cm)Chassis with fan tray,
power supplies, and
MICs: 30 lb (13.6 kg)
Modular chassis
3.35 in. (8.5 cm)18.43 in. 46.81 cm)0.25 in. (0.64 cm)0.1 lb (0.05 kg)Air filter
1.2 in. (3.05 cm)6.8 in (17.3 cm)6.25 in. (15.9 cm)Maximum up to 1.2 lb
(0.54 kg)
MIC
1.2 in. (3.05 cm)6.8 in (17.3 cm)12.5 in. (31.75 cm)1.9 lb (0.9 kg)Dual-wide MIC
3.35 in. (8.5 cm)20.5 in. 52.07 cm)2.75 in. (6.96 cm)2.3 lb (1.04 kg)Fan tray
1.6 in. (4.1 cm)13.2 in. (33.5 cm)2.8 in. (7.1 cm)2.6 lb (1.18 kg)DC power supply
1.6 in. (4.1 cm)13.2 in. (33.5 cm)2.8 in. (7.1 cm)2.6 lb (1.18 kg)AC power supply
See Also MX5, MX10, MX40, and MX80 Router Overview on page 19•
• MX5, MX10, MX40, and MX80 Chassis Description on page 24
• MX5, MX10, MX40 and MX80 Chassis Lifting Guidelines on page 149
