NOTE: USB flash drives used with the QFX Series device must support
USB 2.0 or later.
Related
Documentation
Creating an Emergency Boot Device on page 161•
• Performing a Recovery Installation Using an Emergency Boot Device
Console Port Connector Pinout Information
The console port on a Juniper Networks device is an RS-232 serial interface that uses an
RJ-45 connector to connect to a console management device. The default baud rate for
the console port is 9600 baud.
Table 30 on page 70 provides the pinout information for the RJ-45 console connector.
NOTE: If your laptop or PC does not have a DB-9 male connector pin and you
want to connect your laptop or PC directly to a device, use a combination of
the RJ-45 to DB-9 female adapter and a USB to DB-9 male adapter. You
must provide the USB to DB-9 male adapter.
Table 30: Console Port Connector Pinout Information
DescriptionSignalPin
Request to sendRTS Output1
Data terminal readyDTR Output2
Transmit dataTxD Output3
Signal groundSignal Ground4
Signal groundSignal Ground5
Receive dataRxD Input6
Data carrier detectCD Input7
Clear to sendCTS Input8
Related
Documentation
Connecting a Devicetoa ManagementConsoleby Using an RJ-45 Connector on page 94•
• Configuring the Console Port Type (CLI Procedure)
