RJ-45 Management Port Connector Pinout Information

Table 31 on page 71 provides the pinout information for the RJ-45 connector for the

management port on Juniper Networks devices.

Table 31: RJ-45 Management Port Connector Pinout Information

DescriptionSignalPin

Transmit/receive data pair 1TRP1+1

Transmit/receive data pair 1TRP1-2

Transmit/receive data pair 2TRP2+3

Transmit/receive data pair 3TRP3+4

Transmit/receive data pair 3TRP3-5

Transmit/receive data pair 2TRP2-6

Transmit/receive data pair 4TRP4+7

Transmit/receive data pair 4TRP4-8

Documentation

• Connecting a Device to a Network for Out-of-Band Management on page 93

Chapter 8: Pinout Specifications
