Table 7: SRX220 Services Gateway Front Panel Components (continued)
ComponentNumber
Power button2
LEDs: Status, Alarm, Power, HA, MPIM-1, MPIM-23
Reset Config button4
USB ports5
Console port6
Gigabit Ethernet ports7
CompactFlash card slot8
For more information on the front panel components, see the following topics:
•
SRX220 Services Gateway Built-In Interfaces on page 13
•
SRX220 Services Gateway LEDs on page 16
•
SRX220 Services Gateway Boot Devices and Dual-Root Partitioning Scheme on page 9
SRX220 Services Gateway Back Panel
Figure 2 on page 12 shows the back panel of the SRX220 Services Gateway.
Figure 2: SRX220 Services Gateway Back Panel
Table 8 on page 12 lists the back panel components of the SRX220 Services Gateway.
NOTE: The numbers in Figure 2 on page 12 correspond to the numbers in
Table 8 on page 12.
Table 8: SRX220 Services Gateway Back Panel Components
ComponentNumber
Cable tie holder1
Copyright © 2016, Juniper Networks, Inc.12
SRX220 Services Gateway Hardware Guide for H Model Numbers
