8. Disable flow control by entering AT&K0.
9. Save modem settings by entering AT&W.
Related
Documentation
Connecting to the SRX240 Services Gateway Setup Wizard on page 83•
• Connecting the SRX240 Services Gateway to the CLI on page 85
• Connecting to the CLI at the User End for the SRX240 Services Gateway on page 66
• Connecting the Modem to the Console Port on the SRX240 Services Gateway on
page 65
Connecting the Modem to the Console Port on the SRX240 Services Gateway
To connect the dial-up modem to the console port on the services gateway:
1. Turn off power to the services gateway.
2. Turn off power to the modem.
3. Plug one end of the Ethernet cable supplied with your services gateway into the
console port.
4. Plug the other end of the CAT-5e (Ethernet cable) into the RJ-45 to DB-9 serial port
adapter supplied with your services gateway.
5. Connect the serial port adapter to a separately purchased DB-9 female to DB-25
male adapter or other adapter appropriate for your modem.
6. Plug the modem adapter into the DB-25 connector on the modem.
7. Connect the modem to your telephone network.
8. Turn on the power to the modem.
9. Power on the services gateway by pressing the Power button on the front panel. Verify
that the Power LED on the front panel turns green.
NOTE: Most modems have an RS-232 DB-25 connector. You must
separately purchase an adapter to connect your modem to the RJ-45 to
DB-9 adapter and Ethernet cable supplied with the services gateway.
Related
Documentation
Connecting to the SRX240 Services Gateway Setup Wizard on page 83•
• Connecting the SRX240 Services Gateway to the CLI on page 85
• Connecting the Modem at the SRX240 Services Gateway End on page 64
• Connecting to the CLI at the User End for the SRX240 Services Gateway on page 66
65Copyright © 2015, Juniper Networks, Inc.
Chapter 13: Connecting the SRX240 Services Gateway to External Devices
