CHAPTER 4
1-Port VDSL2 Annex A Mini-Physical
Interface Module
1-Port VDSL2 Annex A Mini-Physical Interface Module (SRX-MP-1VDSL2-R)
Overview on page 25
1-Port VDSL2 Annex A Mini-Physical Interface Module (SRX-MP-1VDSL2-R) Hardware
Specifications on page 26
1-Port VDSL2 Annex A Mini-Physical Interface Module (SRX-MP-1VDSL2-R)
LEDs on page 27
1-Port VDSL2 Annex A Mini-Physical Interface Module (SRX-MP-1VDSL2-R) Supported
Profiles on page 27
1-Port VDSL2 Annex A Mini-Physical Interface Module (SRX-MP-1VDSL2-R) Overview
Very-high-bit-rate digital subscriber line (VDSL) technology is part of the xDSL family of
modem technologies, which provide faster data transmission over a single flat untwisted
or twisted pair of copper wires. The 1-Port VDSL2 Annex A Mini-PIM carries the Ethernet
backplane. When the Mini-PIM is plugged into the chassis, the Mini-PIM connects to one
of the ports of the baseboard switch. The 1-Port VDSL2 Annex A Mini-PIM on the SRX
Series Services Gateway provides ADSL backward compatibility.
The 1-Port VDSL2 Annex A Mini-PIM is compatible with the ITU-T G.993.2 (VDSL2)
standard.
Figure 6 on page 25 shows the 1-Port VDSL2 Annex A (SRX-MP-1VDSL2-R) Mini-PIM.
Figure 6: VDSL2 Annex A (SRX-MP-1VDSL2-R) Mini-PIM
25Copyright © 2017, Juniper Networks, Inc.
