Juniper SRX340 User Manual

The following features are supported on the 1-Port VDSL2 Annex A Mini-Physical Interface
Module (Mini-PIM):
•
ADSL/ADSL2/ADSL2+ backward compatibility with Annex-A, Annex-M support
•
Packet Mode Transfer (PTM) or Ethernet in the First Mile (EFM) (802.3ah) support
•
Operation, Administration, and Maintenance (OAM) support for ADSL/ADSL2/ADSL2+
mode
•
Asynchronous Transfer Mode (ATM) quality of service (QoS) (supported only when
the VDSL2 Mini-PIM is operating in ADSL2 mode)
•
Multilink Point-to-Point Protocol (MLPPP) (supported only when the VDSL2 Mini-PIM
is operating in ADSL2 mode)
•
Support for a maximum of 10 permanent virtual connections (PVCs) (only in
ADSL/ADSL2/ADSL2+ mode)
•
Dying Gasp support (ADSL and VDSL2 mode)
Related
Documentation
1-Port VDSL2 Annex A Mini-Physical Interface Module (SRX-MP-1VDSL2-R) Hardware
Specifications on page 26
•
• 1-Port VDSL2 Annex A Mini-Physical Interface Module (SRX-MP-1VDSL2-R) LEDs on
page 27
• 1-Port VDSL2 Annex A Mini-Physical Interface Module (SRX-MP-1VDSL2-R) Supported
Profiles on page 27
1-Port VDSL2 Annex A Mini-Physical Interface Module (SRX-MP-1VDSL2-R) Hardware
Specifications
Table 18 on page 26 gives the hardware specifications of the 1-Port VDSL2 Annex A
Mini-Physical Interface Module (Mini-PIM).
Table18: 1-Port VDSL2 Annex A (SRX-MP-1VDSL2-R) Mini-PIM Hardware
Specifications
ValueDescription
3.75 in. x 5.9 in. x 0.80 in.
(9.5 cm x 14.5 cm x 2.0 cm)
Dimensions (H x W x L)
4.0 oz (114 g)Weight
RJ-11Connector type
Mini-PIMForm factor
32°F through 113°F (0° C through 40° C)Environmental operating temperature
–40°F through 158°F (–40° C through 70° C)Storage temperature
Copyright © 2017, Juniper Networks, Inc.26
SRX300 Series and SRX550 High Memory Gateway Interface Modules Reference

Juniper SRX340 Specifications

General

Firewall Throughput	3 Gbps
Maximum Concurrent Sessions	256, 000
Memory	4 GB
Redundant Power Supplies	No
Operating Temperature	32°F to 104°F (0°C to 40°C)
Humidity	10% to 90% non-condensing
Storage	8 GB
