CHAPTER 6
16-Port Gigabit Ethernet XPIM (PoE)
•
16-Port Gigabit Ethernet XPIM (PoE) Overview on page 35
•
16-Port Gigabit Ethernet XPIM (PoE) Components on page 36
•
16-Port Gigabit Ethernet XPIM (PoE) Hardware Specifications on page 37
•
16-Port Gigabit Ethernet XPIM (PoE) LEDs on page 37
16-Port Gigabit Ethernet XPIM (PoE) Overview
The 16-Port Gigabit Ethernet XPIM is a double-high, single-wide LAN switch
Gigabit-Backplane Physical Interface Module (GPIM) that uses two standard slots
vertically. It is available with or without Power over Ethernet (PoE) support. The SRX550
High Memory Services Gateway supports the PoE model. The PoE GPIMs provide ports
that supply electric power over the same ports that are used to connect network devices.
For more information about PoE, see “Power over Ethernet Support on SRX550 High
Memory Services Gateway Interfaces” on page 10.
The 16-Port Gigabit Ethernet XPIM must be installed in one of the following 20-Gigabit
slots on the SRX550 High Memory Services Gateway:
•
Slot 3
•
Slot 6
NOTE: The 16-Port Gigabit Ethernet XPIM is supported on both slot 3 and
slot 6 of the SRX550 High Memory Services Gateway. However, the
performance (bandwidth) in slot 3 will be limited as it has a 10G back link.
NOTE: The SRX550 High Memory Services Gateway does not support
hot-swappable functionality for GPIMs.
35Copyright © 2017, Juniper Networks, Inc.
