Juniper SRX340 User Manual

CHAPTER 7
LTE Mini-Physical Interface Module
•
LTE Mini-Physical Interface Module on page 39
•
LTE Mini-Physical Interface Module LEDs on page 42
•
LTE Mini-Physical Interface Module Hardware Specifications on page 43
LTE Mini-Physical Interface Module
The LTE Mini-Physical Interface Module (Mini-PIM) provides wireless WAN support on
the SRX300 Series and SRX550 High Memory Services Gateways. The Mini-PIM contains
an integrated modem and operates over 3G and 4G networks. The Mini-PIM supports up
to two SIM cards and can be installed in any of the Mini-PIM slots on the services
gateways.
The Mini-PIM supports the following features:
•
Automatic switchover between service providers through dual SIMs
•
Storage support for multiple service provider and access point name (APN) profiles
•
LTE carrier aggregation
•
SIM lock and unlock capability
•
Always-on, dial-on-demand, and backup modes
•
Over-the-Air upgrade for modem firmware
Figure 9 on page 39 shows the front panel of the LTE Mini-PIM.
Figure 9: LTE Mini-PIM Front Panel
Table 29 on page 40 lists the components on the front panel of the Mini-PIM.
39Copyright © 2017, Juniper Networks, Inc.
