Table 42: EIA-530A DTE Cable Pinouts for the 1-Port Serial
Mini-PIM (continued)
Description
LFH-60
PairingDB-25 PinLFH-60 Pin
Clear to Send (B)371338
Transmit Data (B)601459
Transmit Clock (A)551556
Receive Data (B)1162
Receive Clock (A)6175
Local Loopback-1841
Request to Send (B)481947
Data Terminal Ready (A)-2033
Signal Ground-234
Terminal Timing (A)512452
---26 to 25
---30 to 29
---18 to 17
Related
Documentation
RS-232 DTE Cable Pinouts for the 1-Port Serial Mini-Physical Interface Module on
page 58
•
• RS-422/449 (EIA-449) DTE Cable Pinouts for the 1-Port Serial Mini-Physical Interface
Module on page 61
• V.35 DTE Cable Pinouts for the 1-Port Serial Mini-Physical Interface Module on page 64
• X.21 DTE Cable Pinouts for the 1-Port Serial Mini-Physical Interface Module on page 66
RS-232 DCE Cable Pinouts for the 1-Port Serial Mini-Physical Interface Module
Table 43 on page 58 gives the RS-232 DCE cable pinouts.
57Copyright © 2017, Juniper Networks, Inc.
Chapter 10: Serial Mini-Physical Interface Module Cable Specifications

Juniper SRX340 Specifications

General

Firewall Throughput	3 Gbps
Maximum Concurrent Sessions	256, 000
Memory	4 GB
Redundant Power Supplies	No
Operating Temperature	32°F to 104°F (0°C to 40°C)
Humidity	10% to 90% non-condensing
Storage	8 GB
