EIA-530A DCE Cable Pinouts for the 1-Port Serial Mini-Physical Interface Module on
page 54
•
• RS-232 DCE Cable Pinouts for the 1-Port Serial Mini-Physical Interface Module on
page 57
• RS-422/449 (EIA-449) DCE Cable Pinouts for the 1-Port Serial Mini-Physical Interface
Module on page 59
• X.21 DCE Cable Pinouts for the 1-Port Serial Mini-Physical Interface Module on page 65
V.35 DTE Cable Pinouts for the 1-Port Serial Mini-Physical Interface Module
Table 48 on page 64 describes the V.35 DTE cable pinouts.
Table 48: V.35 DTE Cable Pinouts for the 1-Port Serial Mini-PIM
Description
LFH-60
PairingM/34 PinLFH-60 Pin
Frame Ground-A15
Signal Ground-B57
Request to Send-C48
Clear to Send-D37
Data Set Ready-E9
Received Line Signal Detector-F13
Data Terminal Ready-H33
Test Mode-K41
Transmit Data (A)59P60
Receive Data (A)2R1
Transmit Data (B)60S59
Receive Data (B)1T2
Terminal Timing (A)51U52
Receive Timing (A)6V5
Terminal Timing (B)52W51
Copyright © 2017, Juniper Networks, Inc.64
SRX300 Series and SRX550 High Memory Gateway Interface Modules Reference

Juniper SRX340 Specifications

General

Firewall Throughput	3 Gbps
Maximum Concurrent Sessions	256, 000
Memory	4 GB
Redundant Power Supplies	No
Operating Temperature	32°F to 104°F (0°C to 40°C)
Humidity	10% to 90% non-condensing
Storage	8 GB
