V.35 DCE Cable Pinouts for the 1-Port Serial Mini-Physical Interface Module
Table 47 on page 63 gives the V.35 DCE cable pinouts.
Table 47: V.35 DCE Cable Pinouts for the 1-Port Serial Mini-PIM
Description
LFH-60
PairingM/34 PinLFH-60 Pin
Frame Ground-A15
Signal Ground-B57
Request to Send-C37
Clear to Send-D48
Data Set Ready-E33
Received Line Signal Detector-F13
Data Terminal Ready-H9
Test Mode-K45
Transmit Data (A)2P1
Receive Data (A)59R60
Transmit Data (B)1S2
Receive Data (B)60T59
Terminal Timing (A)6U5
Receive Timing (A)51V52
Terminal Timing (B)5W6
Receive Timing (B)52X51
Transmit Timing (A)55Y56
Transmit Timing (B)56AA55
---22 to 21
--26 to 25
63Copyright © 2017, Juniper Networks, Inc.
Chapter 10: Serial Mini-Physical Interface Module Cable Specifications

Juniper SRX340 Specifications

General

Firewall Throughput	3 Gbps
Maximum Concurrent Sessions	256, 000
Memory	4 GB
Redundant Power Supplies	No
Operating Temperature	32°F to 104°F (0°C to 40°C)
Humidity	10% to 90% non-condensing
Storage	8 GB
