Table 36 on page 48 lists the RJ-48 connector to RJ-48 connector (crossover) pinouts
for the 1-Port T1/E1 Mini-Physical Interface Module (Mini-PIM).
Table 36: RJ-48 Connector to RJ-48 Connector (Crossover) Pinouts
Signal
RJ-48 Pin (Data
Numbering Form)
RJ-48 Pin (on
T1/E1 Mini-PIM)
RX/Ring/– <––>TX/Ring/–41
RX/Tip/+ <––>TX/Tip/+52
TX/Ring/– <––>RX/Ring/–14
TX/Tip/+ <––>RX/Tip/+25
Shield/Return/Ground33
Shield/Return/Ground66
No connectNo connect7
No connectNo connect8
Related
Documentation
RJ-48 Connector to DB-15 Connector Pinouts for the 1-Port T1/E1 Mini-Physical Interface
Module (SRX-MP-1T1E1-R) on page 48
RJ-48 Connector to DB-15 Connector Pinouts for the 1-Port T1/E1 Mini-Physical Interface
Module (SRX-MP-1T1E1-R)
Table 37 on page 48 lists the RJ-48 connector to DB-15 connector (straight) pinouts.
Table 37: RJ-48 Connector to DB-15 Connector (Straight) Pinouts
Signal
DB-15 Pin (Data Numbering
Form)
RJ-48 Pin (on T1/E1
Mini-PIM)
RX/Ring/– <––>RX/Ring/–111
RX/Tip/+ <––>RX/Tip/+32
TX/Ring/– <––>TX/Ring/–94
TX/Tip/+ <––>TX/Tip/+15
Shield/Return/Ground43
Shield/Return/Ground26
No connectNo connect7
Copyright © 2017, Juniper Networks, Inc.48
SRX300 Series and SRX550 High Memory Gateway Interface Modules Reference
