Juniper SRX340 User Manual

CHAPTER 8
T1/E1 Mini-Physical Interface Module
•
RJ-48 Connector to RJ-48 Connector Pinouts for the 1-Port T1/E1 Mini-Physical Interface
Module (SRX-MP-1T1E1-R) on page 47
•
RJ-48 Connector to DB-15 Connector Pinouts for the 1-Port T1/E1 Mini-Physical Interface
Module (SRX-MP-1T1E1-R) on page 48
RJ-48 Connector to RJ-48 Connector Pinouts for the 1-Port T1/E1 Mini-Physical Interface
Module (SRX-MP-1T1E1-R)
The 1-Port T1/E1 Mini-Physical Interface Module (Mini-PIM) uses an RJ-48 cable, which
is not supplied with the Mini-PIM.
CAUTION: To maintain agency approvals, use only a properly constructed,
shielded cable.
Table 35 on page 47 lists the RJ-48 connector to RJ-48 connector (straight) pinouts.
Table 35: RJ-48 Connector to RJ-48 Connector (Straight) Pinouts
Signal
RJ-48 Pin (Data
Numbering Form)
RJ-48 Pin (on 1-Port
T1/E1 Mini-PIM)
RX, Ring, –11
RX, Tip, +22
TX, Ring, –44
TX, Tip, +55
Shield/Return/Ground33
Shield/Return/Ground66
No connectNo connect7
No connectNo connect8
47Copyright © 2017, Juniper Networks, Inc.

Juniper SRX340 Specifications

General

Firewall Throughput	3 Gbps
Maximum Concurrent Sessions	256, 000
Memory	4 GB
Redundant Power Supplies	No
Operating Temperature	32°F to 104°F (0°C to 40°C)
Humidity	10% to 90% non-condensing
Storage	8 GB
