(8 km @ 0.5 dB/km, or 4 dB) and loss for seven connectors (0.5 dB per connector, or 3.5 dB). The power
margin (P
M
) is calculated as follows:
P
M
= P
B
– LL
P
M
= 13 dB – 8 km (0.5 dB/km) – 7 (0.5 dB)
P
M
= 13 dB – 4 dB – 3.5 dB
P
M
= 5.5 dB
In both examples, the calculated power margin is greater than zero, indicating that the link has sufficient
power for transmission and does not exceed the maximum receiver input power.
RELATED DOCUMENTATION
Signal Loss in Multimode and Single-Mode Fiber-Optic Cable for the SRX3600 Services Gateway | 93
Attenuation and Dispersion in Fiber-Optic Cable for the SRX3600 Services Gateway | 94
Calculating the Power Budget for Fiber-Optic Cable for the SRX3600 Services Gateway | 95
