Two XFP sockets for Ethernet transceivers
Supported XFP transceivers:
10GBASE-ER (model numbers SRX-XFP-10GE-ER and SRX-XFP-10GE-ER-ET )
10GBASE-LR (model numbers SRX-XFP-10GE-LR and SRX-XFP-10GE-LR-ET
10GBASE-SR (model numbers SRX-XFP-10GE-SR and SRX-XFP-10GE-SR-ET )
Cables and
connectors
ONLINE Button–The ONLINE button on the IOC front panel does not perform any function.Controls
•
SRX1400: Front slot labeled 2
•
SRX3400: Front slots labeled 1 through 4 (except as noted below)
•
SRX3600: Front slots labeled 1 through 6 (except as noted below)
NOTE: When an SRX3400 or SRX3600 Services Gateway is in the Express Path (formerly
known as Services Offload) mode supported in Junos OS release 12.1X44-D10 and later,
IOCs are only supported in front panel slots 1 through 3. See the Junos OS documentation
for more information about Express Path mode.
Supported Slots
IOCs are cold-swap-only modules. You must power-off the services gateway before
removing, replacing, or adding IOCs.
Swapping
SERVICE LED, one bicolor
•
Off–The IOC is administratively disabled, butmapped to the NPC.
•
Green–The IOC is mapped to the NPC and is available to carry Ethernet traffic.
•
Amber–The IOC is not mapped to the NPC and is not available to carry Ethernet traffic.
OK/FAIL LED, one bicolor
•
Off–One or more of the following conditions apply:
•
The services gateway is not powered on.
•
The services gateway is still in the process of either booting or shutting down.
•
The services gateway is not configured for chassis clustering.
•
Steady Green–The services gateway is configured for chassis clustering, and the SCM
is operating normally.
•
Blinking Green–The SCM is initializing (preparing to come online) or is preparing to go
offline.
•
Red–The SCM has failed and is not operating normally.
LEDs
41
