Table 13: Physical Specifications
ValueDescription
8.75 in. (22.2 cm) high
17.5 in. (44.5 cm) wide
25.5 in. (64.8 cm) deep (from front-mounting bracket to chassis
rear)
Chassis dimensions
Chassis with midplane, SFB, Routing Engine, fan tray, air filter,
and AC power module: 73 lb (33 kg)
Maximum configuration: 118 lb (54 kg)
Services gateway weight
2.9 lb (1.3 kg)Routing Engine weight
2.0 lb (0.9 kg)SCM weight
5.1 lb (2.3 kg)SFB weight
2.2 lb (1.0 kg)NPC weight
3.7 lb (1.7 kg)SPC weight
2.4 lb (1.1 kg)IOC weight
6.2 lb (2.8 kg)Fan tray weight
0.2 lb (0.09 kg)Air filter weight
2.9 lb (1.3 kg)DC power supply weight
3.1 lb (1.4 kg)AC power supply weight
RELATED DOCUMENTATION
Available Components for the SRX3600 Services Gateway | 5
Hardware Component Locations in the SRX3600 Services Gateway Chassis | 22
SRX3600 Services Gateway Chassis | 21
63
