K-Rain KRC 9 - Pump Connection

19 of 40
Other Features (continued)
Pump Connection
L This unit will allow zones
to be assigned to a pump
® The default position
is that all zones are
assigned to PUMP A [r]
1. Turn the MAIN DIAL to
PUMP SETTINGS
L PUMP A will be active on
ZONE 1 [s] by default
2. Use or to scroll ZONES
3. Use to deactivate
pump when running
the selected ZONE
4. Use to activate
pump when running
the selected ZONE
5. Press again to switch to
PUMP A on PROGRAM 1 [t]
L This allows for pump
activation to be assigned
to PROGRAMS rather
than ZONES
6. Use or to scroll
PROGRAMS
s
t
r
