(continued)
Overload Protection
L Standard 20mm M-205
1amp fast blow glass fuse,
protects against power
surges and electronic fuse
rated to 1AMP protects
against field faults
L Faulty zone skip function
Wiring
® Output circuits should be
installed and protected in
accordance with wiring code
for your location
Power Failure
L The controller has
permanent memory and real
time clock, so the data is
always backed up even with
the absence of all power
L The unit is factory fitted
with a 3V CR2032 lithium
battery with up to 10
years memory backup
L The 9V alkaline battery
maintains the data
during power outages,
and is recommended
to help maintain the life
of the lithium battery
Á Tampering with the unit
will void the warranty
® The batteries do not run
the outputs. The internal
transformer requires mains
power to run the valves
Electrical Specications
