Installation
Mounting Controller
® Install the controller near a
240VAC outlet–preferably
in a house, garage, or
exterior electrical cubicle
® For ease of operation,
eye level placement
is recommended
® Ideally, your controller
location should not
be exposed to rain or
areas prone to flooding
or heavy water
® This inbuilt controller comes
with an internal transformer
and is suitable for outdoor
or indoor installation
® The housing is designed
for outdoor installation
but the plug needs to be
installed in a weatherproof
socket or under cover
® Fasten the controller using
the key hole slot positioned
externally on the top centre
and the additional holes
positioned internally under
the terminal cover
Power Supply Connections
® It is recommended that
the transformer is not
connected to a 240VAC
supply also servicing or
supplying motors (such
as air conditioners, pool
pumps, refrigerators)
® Lighting circuits are
suitable as power sources
