Installation (continued)
Electrical Hook-up
Á Installation must be
carried out in accordance
with these instructions
and all Local, State
and Federal codes
Á Disconnect all
240VAC power before
commencing any wiring
or valve connection
Á Avoid connecting
to a 240VAC supply
also servicing motors
(ie. poolpumps,
refrigerators, etc.)
Field Wiring Connections
1. Prepare wire for hook-up
by cutting the wires to
the correct length and
stripping approx. 6mm of
insulation from the end to be
connected to the controller
L A maximum of 2
solenoid valves can be
run off each output
2. Ensure terminal block
screws are loosened
sufficiently to permit easy
access for wire ends
3. Insert stripped wire ends
into the clamp aperture
and tighten screws
4. Do not over tighten
as this may damage
the terminal block
® A maximum of
0.75amps may be
supplied by any output
5. Check the inrush current of
your solenoid coils before
connecting more than two
valves to any one zone
