Kaba SLA User Manual

0639-990-21---30j_2010.07.indd
SLA
0639-990/22j
Page 12 of 46
Operating instructions
• Doorisclosedandlocked.
• Doorcanbeopenedbyakeycommand.
• OKIandHSK(lightbarriers)actassecondaryswitchingelement.
• IfHSK(lightbarriers)issetpermanently,after30secondsitisclosed
at creepage speed.
• IfDIP3ONissetitwillnotbepushedtoenableamanualunlocking.
• Hold-opentimeis5seconds(notadjustable).
• ThedelayedswitchovertotheoperatingmodeNIGHTcanbeactivated
by means of parameter Tvn. Function: If the program selector switch
is changed to the operating mode NIGHT from any random operating
mode, the internal radar will still remain active during the programmed
time Tvn (EXIT).
• Doorfunctionsinone-waytrafc.
• AccordingtosettingsofDIP2, the locking will lock after having reached
the CLOSED position.
• DoorcanbeopenedbykeyorOKI
• OKAandHSKactassecondaryswitchingelements.
• Doorisnotlocked.
• Doorcanbeopenedwithkey,OKIorOKA.
• AllopeningelementsandHSKactassecondaryswitchingelements.
• Dooropensandremainsunlockedwithoutmainspower.
• Withreducedopening,thedoorwillopencompletely.
• OperatingmodeOPENisnot kept as a proper operating mode on
terminals.
• OperatingmodeOPENcanberealisedviaoperatingmodeMANUAL.
If a reduced OPEN position should be kept with a rubber cable, a key
can be used.
• ProgrammablebymeansofD-BEDIX.
NIGHT
EXIT
AUTOMATIC
MANUAL
(OPEN)
 
 
A reset causes a stop and unlocks the door, afterwards the drive unit activates a new
setting-up procedure.
• Aresetcanbeactivatedbyresetpushbuttononkeyprogramswitchoroncontrolunit.
Alternatively, to activate reset function, push simultaneously (min 1 second) operating
modes MANUAL and EXIT.
• AresetcanbeactivatedbytheD-BEDIX.
