0639-990-21---30j_2010.07.indd
SLA
0639-990/22j
Page 17 of 46
Operating instructions
For the setting procedure the following parameters are learned:
Whenpushingagainsttheclosestoppiece,rsttheCLOSEDpositionisreliablyrecog-
nised. Afterwards the open stop piece is searched out in creeping speed.
Door mass
With a short acceleration the mass of the slide wing(s) is measured. Out of it result the
maximumspeed,creepagedistanceandforces.
In CLOSED position the locking pressure is switched-off for a short time. If door moves
towards the OPEN position, it can be gathered that there is a mechanical emergency
opening MENO.
If the slide wings are impeded during the setting-up procedure, this position is recognised
as travel stops. Therefore a new setting-up procedure will be necessary.
If the sliding wings weight is less than 20 kg,setting-upproceduredataisnotsaved(ex-
cept BAT-NOT). When switching back on, a reset is activated. This allows to install drive
mechanism components and to carry out the operating test in the workshop.
If the sliding wings weight is more than 20 kg, after a power failure, all setting parameters
remain saved (on activating no learning run).
