0639-990-21---30j_2010.07.indd

SLA

LEDDIP-Switch Reset

0639-990/22j

Page 7 of 46

Operating instructions

 

Warning:

Prior to commissioning, make sure that the door installation has not been

subjecttoanymodicationswhichmightcausedangeroussituations:

• Checkthedoorsurroundingsforanystructuralchanges.

• Makesurethatnoobjects(suchasfurniture,pallets,etc.)havebeen

placed close to the door.

 

1. Check if all the drive elements and

options have been cabled (see con-

nectiondiagramintheappendix).

2. Checking/setting of the DIP swit-

ches:

See chapter „Settings“.

3. Switch on power supply system.

4. Select the operating mode AUTOMA-

TIC: the setting-up run.

Note:

Thedoormustcloserst.Whenitopensrst:Checkrightpositionofbelt

coupling(s) or change sense of rotation of the gear motor.

The setting-up procedure is only carried out in the mains-powered mode,

whereas no setting-up is possible in the emergency battery mode because of

the restricted battery power. The control unit STERE is automatically swit-

ched off.

If the sliding wing weight exeeds20kg, all the setting values remain memo-

rized after a mains failure (no learning run upon start-up).

5. Adjust all the radars and presence detectors according to the respective instructions.

6. Set the desired parameters.

7. Check the function.

Adjusting trimmers

Kaba SLA User Manual
