SLA
0639-990/22j
Page 14 of 46
Operating instructions
With emergency battery the door continues to function normally during 15...30 minutes
afterapowerfail.Accelerationandnalspeedofslidingwingsarelowerthanwithpower
from network. Emergency battery is whether controlled nor tested. In case of power failu-
re the emergency battery automatically supplies the control unit.
Charged emergency battery in operating mode:
NIGHT Door is closed and locked
Control unit switches off, wake-up over key
all the others Door keeps on functioning normally
Discharged emergency battery in operating mode:
NIGHT Door is closed and locked
Control unit switches off, wake-up over key
EXIT (DIP2 = ON) Door is opened
or
EXIT locked Door is closed and locked
AUTOMAT Door is opened
MANUAL Door is opened
On power fail the drive unit must open due to the escape way functionality. The control
unit only switches off when the emergency battery is discharged. Consequently, when
switching on operating mode NIGHT, the door can be closed the longest possible.
Reaction after power fail in operating mode:
NACHT Door is closed and locked
Control unit switches off, wake-up over key
EXIT (DIP2 = ON) Door is opened
or
EXIT locked Door is opened
AUTOMAT Door is opened
MANUAL Door is opened
