Operating instructions

Attention:
Avoidanexcessivetighteningoftherubbercablewhichwouldcausethe
sliding wings to bump into each other when opened without mains power!
1. Manually close the sliding wing and block it.
2. Stretch the rubber cable until the spacing between the felt tip pen markings has
increasedto~600mm.Shiftthelooseknotuntilitisagainlocatedrightnexttothe
rubbercablexing.
3. Remove the blocking of the sliding wing, then let the rubber cable pull it to the Open
position. If require tighten the rubber cable.
Attention:
Themaximumdistancebetweenthefelttippenmarkingsmust
(which corresponds to a tension of 60 N).
4. Tightentheknotandcutofftherubbercable(max.distancebetweenthecableend
and the knot = 20 mm).
Rubber cable tightened
Rubber cable untightened
