Description of the menu items:
Overview
You can see the current TCP/IP settings for your Ethernet con-
nection here. For GSM/GPRS units, you can also query the
field strength.
▲ Ethernet
 • AktuelleIP-Adresse(CurrentIPaddress):Showsthe
current IP address that is used in the LAN.
 • Aktuelle Subnet Maske (Current subnet mask):
Shows the current subnet mask that is used in the
LAN.
 • Aktuelles Gateway (Current gateway): Shows the
current gateway address that is used in the LAN.
▲ GSM/GPRS
 • CurrentFieldstrength:Showstheeldstrength.
Settings
In the “Commucation” section, you can make numerous com-
munication settings, e.g. change IP addresses or set the PIN
code for the GSM card. You can set the respective local lan-
guage in the second section, which is the “Language” sec-
tion. In the third section, which is the “Data Logger” section,
you can trigger an inverter scan and activate the power con-
trol function. You can also reset the data logger to its factory
settings.
▲ Communication (Communication)
 • Ethernet
→ Boot protocol
none:
No boot protocol is used.
DHCP:
A DHCP server assigns an IP address to the
Powador-proLOG.
BOOTP:
The BOOTP server assigns an IP address to the
Powador-proLOG.
RARP:
A RARP server assigns an IP address to the
Powador-proLOG.
→ Static IP address:
The IP address that is used when no boot proto
col was selected.
→ Subnet mask:
The subnet mask that is used when one was not
assigned by the BOOTP/DHCP server.
→ Gateway:
The gateway that is used when one was not
assigned by the BOOTP/DHCP server.
• Modem/ISDN/GSM
→ Local IP address:
The IP address that the Powador-proLOG has in the
WAN.
→ Remote IP address:
The IP address that the caller must have on the
WAN.
→ ubnet mask:
The subnet mask in the WAN
→ MSN (for ISDN only): The MSN setting
→ PIN code (for GSM only): The GSM PIN setting
▲ Data Logger
Inverter settings
• Scanstarten(Startscan):Usethisoptiontosearchfor
inverters.
• PowerControlaktivieren(Activatepowercontrol)
• Werkseinstellungensetzen(Setfactorysettings)
Reset to factory settings.
Current Values
The current measured values are displayed here. Various que-
ries are possible, depending on which units are connected.
▲ Analogue Values
Shows the analogue measured values.
▲ Digital values
Shows the digital measured values.
▲ Current Sensors
Shows the measured values for the current sensors.
▲ Inverters
Shows the current power of the individual inverters.
System
In the “Power/Energy” section, you can read the current total
power and the energy that is fed in during various time peri-
ods. The “Alarms/Faults” section shows messages about
faults detected in the system.
▲ Energy DI (Energy of DI)
If at least one digital channel was selected to calculate the
overall system power, the relevant measured value will be
displayed in the following submenus.
→ Aktuelle Leistung (Current power)
→ Ertrag – Heute (Yield today)
→ Ertrag – Gestern (Yield yesterday)
→ Ertrag – Monat (Monthly yield)
→ Ertrag – Jahr (Annual yield)
→ Ertrag – Gesamt (Total yield)
▲ Wechselrichter (Inverters)
If the inverters were selected to calculate the total system
power and energy, the relevant measured value will be dis-
played in the following submenus.
→ Aktuelle Leistung (Current power)
→ Tagesenergie (Daily energy)
→ Vortagesenergie (Previous day’s energy)
→ Monatsenergie (Energy for the month)
→ Jahresenergie (Annual energy)
→ Gesamtenergie (Total energy)
▲ Alarme/Fehler (Alarms/Faults)
Se ction 6 · Start-up
