TECHNICAL DESCRIPTION MULTICAL
®
401
5512-091 GB/02.2008/Rev. J1
13
3.1 Type number, MULTICAL
401
Type 66-
Sensor connection
Pt100 V
Pt500 W
Modules
No module 0
M-Bus/pulse inputs (MC 401) P
Data/pulse output Q
Data/pulse inputs R
M-Bus/pulse inputs S
Radio/pulse inputs U
Radio with external antenna connection/pulse inputs W
Supply
No module 0
Battery, D-cell 2
230 VAC supply module 7
24 VAC supply module 8
Pt500 sensor set
No sensor set 0
Pocket sensor set with 1.5 m cable A
Pocket sensor set with 3.0 m cable B
Short direct sensor set with 1.5 m cable F
Short direct sensor set with 3.0 m cable G
Flow sensor
qp m
3
/h Connection Length mm
0.6 G¾B (R½) 110 1
1.5 G¾B (R½) 110 4
1.5 G¾B (R½) 165 (only Pt500) 5
1.5 G1B (R¾) 130 7
1.5 G1B (R¾) 190 9
3.0 G1B (R¾) 130 A
3.0 G1B (R¾) 190 B
3.0 DN20 190 (only Pt100) C
3.5 G5/4 (R1) 260 D
3.5 DN25 260 (only Pt100) E
6.0 G5/4 (R1) 260 F
6.0 DN25 260 G
10 G2B (R1½) 300 H
10 DN40 300 J
15 DN50 270 K
Country code XXX
In addition, the country code can be used for:
language and approval on type label
flow sensor dynamic range (1:50 and 1:100, respectively)
flow sensor class 2 or 3
marking of PN class
special verification, if any
selection of integration period 28 sec. and 4 sec., respectively
Customer lables (2001-XXX) are integrated in the front label.
