Kamstrup MULTICAL 401 User Manual

TECHNICAL DESCRIPTION MULTICAL
®
401
5512-091 GB/02.2008/Rev. J1
9
2 Technical data
2.1 Approved meter data
MID designation
- Mechanical environment Class M1
- Electro-magnetic environment Class E1
Climatic environment 5…55°C, non condensing, closed location (indoor installation)
EN 1434 designation Accuracy class 2 or 3, environmental class A
Flow sensor types qp 0.6 m
3
/h…qp 15 m
3
/h (see Table 1)
Temperature range, calculator : 10C…160C and : 3 K…150 K
Temperature sensor set Pt500 or Pt100, EN 60751
Media temperature in flow sensor q: 15C…130C
Nom.
flow
Max.
flow
Min.
flow
Min. Cut
off
Pressure
loss
p @ qp
Connection
to flow
sensor
Length
Type number
 m
3
/h  m
3
/h l/hl/hbarmm
66-W/Vx-xx1-xxx qp 0.6 qs 1.2 6 3 0.04 G¾B 110
66-W/Vx-xx4-xxx qp 1.5 qs 3.0 15 3 0.25 G¾B 110
66-Wx-xx5-xxx qp 1.5 qs 3.0 15 3 0.25 G¾B 165
66-W/Vx-xx7-xxx qp 1.5 qs 3.0 15 3 0.25 G1B 130
66-W/Vx-xx9-xxx qp 1.5 qs 3.0 15 3 0.25 G1B 190
66-W/Vx-xxA-xxx qp 3.0 qs 6.0 30 6 0.05 G1B 130
66-W/Vx-xxB-xxx qp 3.0 qs 6.0 30 6 0.05 G1B 190
66-Vx-xxC-xxx qp 3.0 qs 6.0 30 6 0.05 DN20 190
66-W/Vx-xxD-xxx qp 3.5 qs 7.0 35 7 0.07 G5/4B 260
66-Vx-xxE-xxx qp 3.5 qs 7.0 35 7 0.07 DN25 260
66-W/Vx-xxF-xxx qp 6.0 qs 12 60 12 0.19 G5/4B 260
66-W/Vx-xxG-xxx qp 6.0 qs 12 60 12 0.19 DN25 260
66-W/Vx-xxH-xxx qp 10 qs 20 100 20 0.06 G2B 300
66-W/Vx-xxJ-xxx qp 10 qs 20 100 20 0.06 DN40 300
66-W/Vx-xxK-xxx qp 15 qs 30 150 30 0.14 DN50 270
Table 1
