12.3 Data strings
Following data strings are compatible with the corresponding data strings in MULTICAL
®
Compact, MULTICAL
®
III,
and MULTICAL
®
66-CDE. The data strings can be read via an optical reading head or via the data terminals on the
plug-in modules.
Please note that 300 baud is used at request and 1200 baud at data.
For analytical purposes of /#5 monthly data, we recommend Kamstrup software METERTOOL LogView, type
66-99-703.
Req STANDARD DATA 1
/#1 Energy Volume Hours T1 T2 T1-T2 Power Flow Peak
power/flow
actual
Info
7 ascii 7 ascii 7 ascii 7 ascii 7 ascii 7 ascii 7 ascii 7 ascii 7 ascii 7 ascii
Req STANDARD DATA 2
/#2 Cust. No. TA2 TL2 TA3 TL3 In-A In-B ABCCC DDEFFGG Date
11 ascii 7 ascii 7 ascii 7 ascii 7 ascii 7 ascii 7 ascii 7 ascii 7 ascii 7 ascii
Req TARGET DATA
/#3 Cust. No. Reading
day
Energy Volume TA2 TA3 In-A In-B Peak
power/flow
year
11 ascii 7 ascii 7 ascii 7 ascii 7 ascii 7 ascii 7 ascii 7 ascii 7 ascii
Req MONTHLY DATA
/#5 Cust. No. Reading
date
Energy Volume TA2 TA3 In-A In-B Peak
power/flow
actual
Reading
date
Energy Volume TA2 TA3 In-A In-B Peak
power/flow
month
25 months back
26 Blank
27 Blank
29 Blank
30 Blank
31 Blank
11 ascii 7 ascii 7 ascii 7 ascii 7 ascii 7 ascii 7 ascii 7 ascii 7 ascii
Table 20
