TECHNICAL DESCRIPTION MULTICAL
®
401
5512-091 GB/02.2008/Rev. J1
17
3.3.2 >E< CONFIGURATION OF MULTITARIF
E= TARIFF TYPE Fn Pil FUNCTION
0 No tariff active - - No function
1 Power tariff Yes 7 Energy is accumulated in TA2 and TA3 based on the power limites in TL2 and TL3.
2 Flow tariff Yes 8 Energy is accumulated in TA2 and TA3 based on the flow limits in TL2 and TL3.
3 Cooling tariff Yes 6
Energy is accumulated in TA2 and TA3 based on the t limits in TL2 and TL3.
4
tRmtFm
33

--
TA2 =
tRm TA3 and tFm
33

5 Return temperature tariff Yes 5
Energy is accumulated in TA2 and TA3 based on the t
R
limits in TL2 and TL3.
3.3.3 >FF< Input a, >GG< Input b, pulse division (f  0.5 Hz)
Input a
Terminal 65-66
Input b
Terminal 67-68
FF
Max. input
GG
Max. input
Pre-counter l/pulse
Measuring unit and decimal
point
00 OFF 00 OFF - - - -
01 50 m³/h 01 50 m³/h 1 100 m³a – m³b 000000.0
02 25 m³/h 02 25 m³/h 2 50 m³a – m³b 000000.0
03 12 m³/h 03 12 m³/h 4 25 m³a – m³b 000000.0
04 5 m³/h 04 5 m³/h 10 10 m³a – m³b 000000.0
05 2.5 m³/h 05 2.5 m³/h 20 5.0 m³a – m³b 000000.0
06 1 m³/h 06 1 m³/h 40 2.5 m³a – m³b 000000.0
07 0.5 m³/h 07 0.5 m³/h 100 1.0 m³a – m³b 000000.0
24
5 m³/h
24
5 m³/h
1 10
m³a – m³b
00000.00
25
2.5 m³/h
25
2.5 m³/h
2 5.0
m³a – m³b
00000.00
26
1 m³/h
26
1 m³/h
4 2.5
m³a – m³b
00000.00
27
0.5 m³/h
27
0.5 m³/h
10 1.0
m³a – m³b
00000.00
40 500 m³/h 40 500 m³/h 1 1000
m³a – m³b
0000000
NB: Electricity meters are not to be connected due to the low frequency allowed (min. 1 sec. pulse and pause)
3.3.4 >FF< Output A, >GG<
Output A
(CE) Terminal 16-17
FF
Pulse
duration
GG
00 OFF 00 OFF
94
1 msec.
95
30 msec.
96
0.1 sec.
3.3.5 >FF< og >GG<
When FF=00 and GG=00 the pulse inputs/outputs are not active
