ERGOcom 3
5 Operation | 5.2 Operation, no display interface (classic)
Note
If there is no input for 8 seconds, the ERGOcom 3 switches back to operational
mode.
This saves the last setting on the status display.
5.2.5 Generate still
Prerequisite
● A video signal is shown on Display 1.
●
TheERGOcom 3 is connected to a PC fitted with a grabber card by means of a
USB cable.
●
On this PC, the KaVo Display Interface System software is installed.
▶ Hold down the footswitch for < 2 seconds.
The Generate still command is passed on to the PC.
5.2.6 Save still
Prerequisite
●
TheERGOcom 3 is connected to a PC fitted with a grabber card by means of a
USB cable.
●
On this PC, the KaVo Display Interface System software is installed.
▶ Hold down the footswitch for > 2 seconds.
The Generate still command is passed on to the PC.
33/56
