KaVo ERGOcom 3 - OSD Display Interface; Cursor Keys

User instructions ERGOremote
5 Operation | 5.1 Controls/displays
5.1.9 OSD Display Interface
▶ Press the OSD button.
The On Screen Display appears.
See also: ERGOcom 3 Instructions for Use
5.1.10 Cursor keys
Joystick
Prerequisite
The corresponding PC is connected via the USB interface of ERGOcom 3 .
The joystick can be used to move the cursor on the PC interface.
If the z axis in ERGOcom 3 is activated, you can perform click and double-click
functions by placing axial pressure on the joystick.
Up
In VGA mode, the up button is used to scroll through active menus.
In Video mode and OSD (Display Interface) mode, it can be used to navigate bet‐
ween the four images.
Right
In VGA mode, the right button is used to control the cursor - equivalent to the right-
hand mouse button.
In Video mode and OSD (Display Interface) mode, it can be used to navigate bet‐
ween the four images.
Left
In VGA mode, the left button is used to control the cursor - equivalent to the left-
hand mouse button.
In Video mode and OSD (Display Interface) mode, it can be used to navigate bet‐
ween the four images.
19/25
