Appendix
MIDI Implementation
3 Exclusive Data
3.1 MMC Commands
No. Description Value Notes
1 Exclusive F0H
2 Universal Real Time 7FH
3 Device ID 0-7FH
4 MMC command 06H
5 Command Number 01-0DH * see table right
6 EOX F7H
*Sending by [RECORDER CONTROL] buttons
* Transmit only
MMC Commands
01 STOP 08 RECORD PAUSE
02 PLAY 09 PAUSE
03 DEFERRED PLAY 0A EJECT
04 FAST FORWARD 0B CHASE
05 REWIND 0C COMMAND ERROR RESET
06 RECORD STROBE 0D MMC RESET
07 RECORD EXIT
3.2 Parameter Send
No. Description Value Notes
1 Exclusive F0H
2 KAWAI ID 40H
3 Channel no. 0-0FH,7FH System Channel = 0-FH, Global = 7FH
4 Function no. 10H Parameter Send
5 Group no. 00H MI Group ID
6 Machine no. 13H Machine ID
7 data1 50-5FH Command ID
8 data2 0-7FH Sub Command ID
9 data3 0-7FH Part number (System = 7FH)
10 data4~ 0-7FH data max 18byte
EOX F7H
Part number :
MP7SE *pp=00~07
00H INT1 (MAIN)
01H INT2 (SUB1)
02H INT3 (SUB3)
03H INT4 (SUB3)
04H EXT1 (MAIN)
05H EXT2 (SUB1)
06H EXT3 (SUB2)
07H EXT4 (SUB3)
08H -reserved-
09H INT-COMMON
0AH EXT-COMMON
7FH SYSTEM/COMMON
