Kawai MP7SE - Controllers; Damper Pedal; Soft Pedal Depth

49
EDIT Menu
EDIT Menu parameters (INT mode)
6 Controllers
1. Damper Pedal
on, off
This parameter determines whether or not the included F-10H
damper pedal is active for the selected sound.
* For more information about connecting pedals, please refer to page 17.
2. Damper Pedal Assign
28 functions (main)
18
functions (sub)
This parameter selects the function assigned to the included
F-10H damper pedal.
* This parameter is common for all four zones.
3. Damper Pedal Mode
normal, Hold
This parameter determines whether or not the damper pedal
should sustain sounds indenitely without decay.
4. Pitch Bend on, off
This parameter determines whether or not the pitch bend
wheel is active for the selected sound.
5. Pitch Bend Range value: 0 ~ 7
This parameter sets the range of the pitch bend wheel in semi-
tone steps.
* The range diers for INT mode (0 ~7) and EXT mode (0~12).
6. Soft Pedal Depth value: 1 ~ 10
This parameter adjusts the eectiveness (i.e. depth/strength) of
the soft pedal.
7. Modulation Wheel on, reverse, off
This parameter determines whether or not the modulation
wheel is active for the selected sound.
When set to ‘Reverse’, the wheel’s output values will be inverted.
8. Modulation Wheel Assign
28 functions (main)
18
functions (sub)
This parameter selects the function assigned to the MP7SE’s
modulation wheel.
9. Modulation Depth Range value: 0 ~ 127
This parameter sets the range of the pitch modulation function
in steps of 600/127 cents.
10. SW1 Button on, off
This parameter determines whether or not the SW1 button is
active for the selected sound.
11. SW1 Button Assign 10 functions
This parameter selects the function assigned to the SW1 button.
* This parameter is common for all four zones.
12. SW2 Button on, off
This parameter determines whether or not the SW2 button is
active for the selected sound.
13. SW2 Button Assign 10 functions
This parameter selects the function assigned to the SW2 button.
* This parameter is common for all four zones.
