3.9.4 Display norm
KEBCOMBIVERTofferstheuserthepossibilitytodenetheownstandardizations in the CP mode. Parame-
ters ud.18...20 serve as conversion, ud.21 serves as specication of the calculation method, decimal places,
as well as the displayed unity in KEB COMBIVIS.
3.9.4Deneownstandardizations
Default
ud.19 multiplier
± 32767
ud.20 offset
± 32767
ud.18 divisor
± 32767
ud.21 ctrl. display norm
0...1791
CP.xx = (selected parameter + ud.20) x ud.19 x unit
ud.18
ud.19 multiplier
± 32767
ud.20 offset
± 32767
ud.18 divisor
± 32767
CP.xx = ud.19 x unit
(selected parameter + ud.20) x ud.18
Inverted
For the "selected parameter" either "non-standardized value" or "standardized value/resolution" is used !
ud.18 Divisor display norm
Adjusts the divisor in the range of ±32767 (default 1). The parameter is set-programmable.
ud.19 Multiplier display norm
Adjusts the multiplier in the range of ±32767 (default 1). The parameter is set-programmable.
ud.20 Offset display norm
Adjusts the offset in the range of ±32767 (default 0). The parameter is set-programmable.
ud.21 Control display norm
ud.21 adjusts the calculation mode, decimal places as well as the displayed unity in KEB COMBIVIS. The pa-
rameter is bit-coded and set-programmable. The parameter can be adjusted in the range of 0...1791.
