Page 3.9 - 8 COMBIVERT R6-S © KEB, 2008-02
Dene CP-Parameters
Bit 12...15 Bit 11...8 Bit 7...6 Bit 5...0 ud.21
- - - see table 1 Unity
- - see table 2 - Mode of calcula-
tion
- see table 3 - - Display
free - - - -
Table 1 unity (bit 0...5)
Value Unity Value Unity Value Unity Value Unity
0 no 16 km/h 32 K 48 lbin
1 mm 17 1/min 33
m
W
49 in/s
2 cm 18 Hz 34
W
50 ft/s
3 M 19 kHz 35
k
W
51 ft/min
4 km 20 mV 36 inc 52 ft/s²
5 G 21 V 37 % 53 ft/s³
6 kg 22 kV 38 kWh 54 MPH
7 us 23 mW 39 mH 55 kp
8 ms 24 W 40 - 56 psi
9 s 25 kW 41 - 57 °F
10 h 26 VA 42 in 58 -
11 Nm 27 kVA 43 ft 59 -
12 kNm 28 mA 44 yd 60 -
13 m/s 29 A 45 oz 61 -
14 m/s
2
30 kA 46 lb 62 -
15 m/s
3
31 °C 47 lbft 63 -
