Page 3.2 - 6 COMBIVERT R6-S © KEB, 2008-02

Operating and appliance data

Parameter Addr. R PG E Min. value Max. value Res. [?] Default

ru.13 Actual DC utilization 020Dh ro - - 0 255 1 % -

Display of the actual utilization referring to the rated current of the regenerative unit. Only positive values

are displayed, whereby a differentiation between supply and regeneration is not possible.

Parameter Addr. R PG E Min. value Max. value Res. [?] Default

ru.14 Actual DC peak utilization 020Eh rw - - 0 255 1 % -

ru.14 enables to recognize short-term peak utilization within an operating cycle. For that the highest value

of ru.13 is stored in ru.14. The peak value memory can be cleared by pressing the UP, DOWN or ENTER

key or via bus by writing any value you like to the address of ru.14. Switching off COMBIVERT R6-S also

clears the memory.

Parameter Addr. R PG E Min. value Max. value Res. [?] Default

ru.15 DC output current 020Fh ro - - 0,0 6553,5 0,1 A -

Display of the actual DC output current in ampere.

Parameter Addr. R PG E Min. value Max. value Res. [?] Default

ru.16 DC output current / peak value 0210h rw - - 0,0 6553,5 0,1 A -

ru.16 enables to recognize short-term peak utilization within an operating cycle. For that the highest value

of ru.15 is stored in ru.16. The peak value memory can be cleared by pressing the UP, DOWN or ENTER

key or via bus by writing any value you like to the address of ru.16. Switching off COMBIVERT R6-S also

clears the memory.

Parameter Addr. R PG E Min. value Max. value Res. [?] Default

ru.17 AC input current 0211h ro - - -3276,7 3276,7 0,1 A -

Display of the actual input current.

Parameter Addr. R PG E Min. value Max. value Res. [?] Default

ru.18

DC voltage /

reference value

212h ro - - 0 1000 1 V -

The DC voltage is measured at switching on and stored as reference value. The regenerative level (cS.02)

refers proportionally to this reference value and follows to the mains voltage.

Parameter Addr. R PG E Min. value Max. value Res. [?] Default

ru.19 DC output voltage 0213h ro - - 0 1000 1 V -

Display of the actual DC output voltage. The value is measured at the DC output terminals of the

COMBIVERT R6-S.
