Keithley 2100 User Manual

Keithley Instruments, Inc.
28775 Aurora Road
Cleveland, Ohio 44139
1-888-KEITHLEY
www.keithley.com
Model 2100
6 1/2-Digit Resolution Digital Multimeter Specifications
Specifications are subject to change without notice.
SPEC-2100 Rev. C / Sep 2011 Page 3 of 4
Function Range Frequency (Hz)
1 Year (% of reading)
23º C ± 5º C
3-5 0.10
5-40 0.05
Frequency and
Period
100mV
to
750V
7
40-300k 0.01
Function Range Resolution Frequency (Hz)
1 year
(23°C ± 5°C)
3-5 1.15 + 0.05
5-10 0.45 + 0.05
10-20k 0.08 + 0.05
20k-50k 0.15 + 0.06
50k-100k 0.70 + 0.09
100.0000mV 0.1uV
100k-300k 4.25 + 0.60
3-5 1.10 + 0.04
5-10 0.4 + 0.04
10-20k 0.08 + 0.04
20k-50k 0.14 + 0.06
50k-100k 0.70 + 0.08
ACV
(AC TRMS
voltage)
1.000000V
to
750.000V
8
1.0uV
To
1mV
100k-300k 4.35 + 0.50
3-5 1.10 + 0.05
5-10 0.40 + 0.05
1.000000A 1uA
10-5k 0.15 + 0.05
3-5 1.25 + 0.07
5-10 0.45 + 0.07
ACI
(AC TRMS
current)
3.000000A 10uA
10-5k 0.20 + 0.07
2. GENERAL SPECIFICATIONS
6
Specifications valid for 2-hour warm-up at 6 1/2 digits:
a. Slow ac filter (3Hz bandwidth).
b. Pure sine wave input greater than 5% of range.
7
750Vac range is limited to 100kHz.
8
750Vac range is limited to 100kHz.

Keithley 2100 Specifications

General

DC Voltage Range	100 mV to 1000 V
AC Voltage Range	100 mV to 750 V
Resistance Range	100 Ω to 100 MΩ
Continuity	Yes
Diode Test	Yes
Frequency Range	3 Hz to 300 kHz
DC Voltage Accuracy	0.0035%
DC Current Range	100 µA to 10 A
DC Current Accuracy	0.05%
AC Current Range	100 µA to 10 A
Frequency Accuracy	0.01%
Capacitance Range	1 nF to 10 mF
Temperature Range	-200 °C
Connectivity	RS-232
Type	6.5-digit digital multimeter
