Keithley 2100 User Manual

Section 2
Getting Started
In this section:
Topic Page
Overview............................................................................................. 2-2
Setting up the Model 2100 Digital Multimeter ..................................... 2-2
Adjusting the handle ..................................................................... 2-2
Setting the line voltage ................................................................. 2-4
Connecting the power................................................................... 2-7
Changing the fuses....................................................................... 2-9
Factory default settings ................................................................ 2-18
Model 2100 familiarization .................................................................. 2-19
The front panel.............................................................................. 2-19
The display ................................................................................... 2-21
The rear panel .............................................................................. 2-23

Keithley 2100 Specifications

General

DC Voltage Range	100 mV to 1000 V
AC Voltage Range	100 mV to 750 V
Resistance Range	100 Ω to 100 MΩ
Continuity	Yes
Diode Test	Yes
Frequency Range	3 Hz to 300 kHz
DC Voltage Accuracy	0.0035%
DC Current Range	100 µA to 10 A
DC Current Accuracy	0.05%
AC Current Range	100 µA to 10 A
Frequency Accuracy	0.01%
Capacitance Range	1 nF to 10 mF
Temperature Range	-200 °C
Connectivity	RS-232
Type	6.5-digit digital multimeter
